Heat Pump Water Heater Energy Efficiency Testing Laboratory with Single Door

Basic Info

Model NO.	DMS-036
Origin	China
HS Code	9024101000
Production Capacity	1000

Product Description

Energy Efficiency Testing Lab Temperature and Humidity Room for Household Refrigerator Freezers

Detailed Product Description

UUT:	Refrigerator & Freezers	Chamber External Dimensions:	6000W×11000D×3500H
Chamber Doors:	Single Door, 2 Set	Test Station:	Can Be Customized
High Light:	energy efficiency testing laboratory , energy efficiency lab test equipment

Overview:

The refrigerator & freezer performance lab consists of one testing chamber, the freezing capacity, energy consumption and other performances of refrigerator and freezers can be tested. This installation can be used to test the performance of 8 household vertical refrigerators or 4 Freezers, and can also be used for other standard operating condition related tests and expanded tests, meeting the needs for product sampling inspection and product development.

In this test system, the operation of the equipment is controlled by a programmable controller and a HMI, test data are collected by a high accuracy data collector, the data can be transferred at real time to an upper level computer for processing, the test reports can be displayed, stored, output and printed through the computer.

Standards:

Design and Testing according to the following standards:

ISO 15502: 2005(ISO 5155, ISO 7371, ISO 28187, ISO 8561)

IEC 62552-1,IEC 62552-3

SASO 2664

Other standards can be customized

Testing Contents:

Storage Temperatures

Cooling Speed

Energy consumption

Freezing Test (Base ISO 15502:2005)

Load Temperature rise time

Ice Making Capacity,Freezing Capacity

Voltage, Current, Power, Power factor

Working coefficient

Enclosure sweat test

*Detailed test method and calculation according to the standards.

Structure:

This test room consists of 2 test chambers, mainly including the room structure, 2 set of air conditioning device,

2 set of electrical control system, and 2 set of measuring system.

Test Chamber Temperature and Humidity:

Name	Sensor	Transducer	Controller	Regulator
Type	R221-30	-	UT-55A	PAC Series
Range	0.00~60.00ºC 20~100%RH	-	0.00~100.00ºC
Accuracy	±0.2ºC ±2%RH	-	±0.1ºC	±1.0%
Input	Pt100 Ω	-	DC 1~5V	4~20mA
Output	-	-	4~20mA	AC 1Φ 230V
Remark	-	-	RS485	FUSE
Maker	CHINO	-	YOKOGAWA	Ximanden
Number	2		4	4

Company Profile

Located in Shenzhen (Nanshan) Hi-Tech Park, Damsion Measuring and Control Equipment is an Instrument manufacturing company integrating scientific research, manufacturing and consulting services. It specializes in the development and production of test equipment that meets IEC, GB and other standards. Damsion also undertakes laboratory system integration projects for professional testing institutions and product manufacturers. With the purpose of "Building first-class testing equipment for China labs", Damsion has established an independent research and development center and introduced the most advanced technology abroad and international high-tech talents. More than 160 products in 12 series have been developed by Damsion's creative design idea: Guided by sensor data acquisition techniques, LED by computer control techniques, and centered on high-precision, low-noise transmission.Testing Equipment of:Wire and cable Material Flammability Electric toolsPlug and socket Switch life Electrical accessoriesLamp Home appliance Dustproof and waterproofImaging products IT products Battery Mask Damsion's rigorous and efficient manufacturing department provides a powerful safeguard for product output. We take every link fastidiously, including selection of materials, inspection of supplied materials, control of the production process, and check of quality testing, and operate with standardized procedures. The company's products have passed ISO9001 management system certification, ISO1400 environmental management system certification, and ISO18001 occupational health and safety system certification, expecting safer and superior products for customers. Users of Damsion in the domestic market include Entry-Exit Inspection and Quarantine Bureau, Technical Supervision Bureau, Product Quality Supervision and Inspection Institute, UL Laboratory, TUV (Rhineland), SGS (General Standard), and various electronic and electrical manufacturers. Products are exported to the international market, and agents have been set up in Hong Kong, Vietnam, Singapore, Thailand, Iran, India, Germany and other regions and countries. Service is an indispensable element to enhance the company's competitiveness. Damsion always regards improving the level and value of as direction. Before sales, we have a professional engineering team to provide customers with a full range of consulting and customized services; After sales, we also have the team to provide timely and satisfactory technical support and product maintenance. With excellent product competitiveness and perfect service, the company has successfully won the trust of many customers. Relying on technological progress, continuously improving efficiency and product quality, insistently serving the market with high-quality products, Damsion is committed to becoming a leader in the testing equipment industry.
1.
Q: Are your company a trading or factory ?
A: Factory +Trade (integration) , since 2004, we focuses on developing and manutfacturing Lab testing equipment.(testing equipment, measuring instrument, laboratory instrument, lab testing equipment, mask testing equipment) and exporting experience , OEM also acceptance for us.2.
Q: After an order is placed,when to deliver ?
A: Generally about 7-30 work days.3.
Q: Do you have any certificate about your factory ?
A: We are already got SGS , ISO 9001 and some testing machine's patent cerificate.4.
Q: What about the Warranty with after-sales service ?
A: We have one year warranty time , when the testing instrument have problems and the customer notice us.We received the customer problems feedback ,we will reply and help customer to solve the problem at first time.5.
Q: How about your testing instrument data accurate ?
A: About our testing instrument's data accuracy, customers can be assured, because many government's lab by our factory help to plan and established.
